5.2.3 Change door-frame acrylic soft-lamp-bar
1. Assess the damaged position of soft light-bars on the door-frame and there are 2 soft
light-bars, which are on the left-side and right-side.
2. If the soft light-bar on the right side is damaged, use the key to open the acrylic door,
remove 2 nuts that fix the iron-sheet and remove the iron-sheet.
3. Press 2 red buttons to move the net down.(if the soft light-bar on the left side is damaged,
step 3 and 4 are not needed)
4. Remove 2 screws on the right side to fix the net pillar and remove the screen pillar.
5. Remove the screws and nuts that fix the mould-weight on the door frame.
6. Pull out the corresponding terminal.
Acryl
The weights
6 nuts
5 screws
41
