WAHLAP TECH PUSHING POINTS - Replacement of Top; Replacement of Speaker

5.2.23 Replacement of top
5.2.24 Replacement of speaker
3. Remove the prize net, reinstall in a reverse order after replacing.
1. Use the key to open the acrylic door, use the iron-bar to pass through the jacking-rod hole
and remove the screw to fix the top.
2. Remove the top, reinstall in a reverse order after replacing.
Diameter of large top：25mm
Diameter of small top：18mm
Diameter of straight top：14mm
1. Open the lower access door of the game-machine with the key.
2. Remove 4 screws on the loudspeaker, pull out the corresponding terminal and remove the
loudspeaker, reinstall in a reverse order after replacing.
4' 8Ω/15W
53
