WAHLAP TECH PUSHING POINTS - Net Movable-Pin Components(PP-0703000)

6.8.3 Net movable-pin components (PP-0703000)
3
Hexagon nut with flange
M3（color coating）
4
2
Spring cotter White cover-bolt
1
1 PP-0703A01
netscreen-pin fixed-iron
SPCC-1.5T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
3
4
2
1
1
1
Note：If the hole can not be passed through,
the hole can be suitably expanded
105
1.6.LM203013
1.4.TH020040
