WAHLAP TECH PUSHING POINTS - Total Components(PP-0000000)

6.2 Total components (PP-0000000)
66
7
1
9
1
8
5
8
5
6
1
4
1
3
1
2
1
1
1
5
1
10
1
Note：After inspecting, the
moving-parts of X/Y axes
should be fastened on the
right side of the game-machine
with the cable ties.
Note：The fixing screws used for each
component are provided in the components.
10 PP-0000A01
Horizontally-moving
drag-chain cover-plate
SPCC-1.2T 1
9 PP-1000000
POP components
1
8 PP-0900000
Prize displaying-board
components
5
7 PP-0800000
Prize-channel cover-plate
components
1
6 PP-0700000
Ramp-net components
1
5 PP-0500000
Moving-parts components
1
4 PP-0400000
Big door-frame components
1
3 PP-0300000
Coin-door components
1
2 PP-0200000
Control-panel components
1
1 PP-0100000
Secondary frame components
SN Name Qty
Drawing No.
Materials/specifications
Note
1
