6.3.2 Power-box components (PP-0102000 )
69
8
1
1
1
6
1
2
1
5
1
4
1
3
1
7
2
10
2
9
4
11
1
12
2
12
hexagon nut with flange
M3（color-coating）
2
11
Pulse-group filter
YB24D3-6A-Q 1
10
Hexagon socket flat-head screw
M4*40（chrome plated）
2
9
Hexagon socket flat-head screw
M4*8（chrome plated）
4
8
hexagon nut with flange
M4（color-coating）
1
7
Cross flat-head screw
M3*8（chrome plated）
2
6
Leakage protection switch CHNT NL18-20
1
5
Fuse tube
218 series T3.15A/5*20 250V
1
4
Cartridge fuse
Cross-head MF527A
1
3
rocker type switch
4P KCD7-2211N 1
2
filter
15GEEG3E 10A/250V
1
1 PP-0102A01
Power inlet box
SPCC-1.2T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.4.LB100010
1.4.SW802011
1.4.LB100020
1.4.SW604010
1.4.BX300010
1.4.BX110050
1.6.LS230032
1.6.LM204013
1.6.LS140032
1.6.LS144012
1.6.LM203013
