7. Remove the soft light-bar, reinstall in a reverse order after replacing.
5.2.4 Change prize-outlet soft-lamp-bar
1. Remove 8 screws that fix the mould-weight at the prize outlet and remove the mould-weight
and acryl at the prize outlet.
2. Pull out the corresponding terminal，Remove the soft light-bar, reinstall in a reverse order
after replacing.
DC12V RGB60 lamp L=1350mm
Soft-lamp-bar
Both sides: DC12V RGB60 lamp L=2050mm
Soft-lamp-bar
42
5.2.5 Change control-panel soft-lamp-bar
1. Turn off the game-machine. Open the acrylic door with the key, remove the screen and 2
screws that fix the service-hatch cover-plate and remove the service-hatch cover-plate.
2. Remove 4 screws that fix the control panel and remove the control panel.
