5.2.31 Replacement of sealing-door spring
3. Remove 3 screws to fix the jacking-rod.
4. Remove the jacking-rod, reinstall in a reverse order after replacing.
57
Jacking-rod
The jacking-rod should be cleaned regularly to avoid oil-slick.
Warning
1. Remove 2 screws to fix the small-door on the left-side of the game-machine.
2. Remove 4 nuts that fix the sealing-plate motor.
3. Remove the door-sealing spring, reinstall in a reverse order after replacing.
Note：1. The screws shall be screwed in as far as
possible to prevent the scratching!
2. The screw head shall be parallel to the shaft!
