WAHLAP TECH PUSHING POINTS - Horizontally-Moving Roller-Plate Components(PP-0502000-A)

2
4
1
1
3
1
4
1
4
Cross flat-head screw
M3*12（chrome plated）
1
3
Sensor
KI1300-AA07LF 1
2
Resin bearing
DR22C2 4
1 PP-0502A03
Horizentally-moving backseat
SPCC-1.2T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
6.7.2.1 Horizontally-moving roller-plate components (PP-0502000-A)
92
1.6.LS231022
5.4.WECHE0004
1.4.ZC030017
