WAHLAP TECH PUSHING POINTS - Prize Sealing-Plate Door Components(PP-0112000)

81
6.3.12 Prize sealing-plate door components (PP-0112000)
10
1
2
1
5
1
11
2
9
2
6
1
3
1
4
1
12
1
1
1
13
4
14
4
7
2
18
4
17
6
8
2
16
1
15
1
17
2
Note：
Padding with EVA sponge：2*18mm
Note：Applying
with screw glue
Note：Applying
with screw glue
Note：
Padding with EVA sponge：2*18mm
Note：1. The screws shall be screwed
in as far as possible to prevent
the scratching!
2. The screw head shall be parallel
to the shaft!
18
Hexagon nut with flange
M4（color coating）
4
17
Cross flat-head screw
M4*12（chrome plated）
6
16
Hexagon socket-head cap screw
M4*10（stainless steel）
1
15
Headless socket screw
M4*6（black coating）
1
14
Cross flat-head screw
M4*8（chrome plated）
4
13
Cross countersunk-head screw
M4*12（black coating）
4
12
Cross round-head screw
M3*6（chrome plated）
1
11
Split washer (e-buckle) M6(black coating) 2
10
Brace for spring stretch AIPOZ8-20 1
9
Flange bearing F698ZZ 2
8 PP-0112A08
Lower cushion
2
7 PP-0112A07
Sealing-plate gasket
SPCC-1.5T 2
6 PP-0112A06
Left-turn shaft seat-iron for
outlet door
SPCC-2.0T 1
5 PP-0112A05
Retaining ring for outlet door
45 1
4 PP-0112A04
Right outlet-sensing baffle
SPCC-1.0T 1
3 PP-0112A03
Outlet door-seal shaft
45 1
2 PP-0112A02
No.2 outlet spring hanging-iron
SPCC-2.0T 1
1 PP-0112A01
Outlet sealing-door
SPCC-1.2T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.6.LM204013
1.6.LS241022
1.6.LSF41015
1.6.LST40011#
1.6.LS240022
1.6.LSC41021
1.6.LS830012
1.6.DQ106011
1.4.HY010031
1.4.ZC000066
