WAHLAP TECH PUSHING POINTS - General Moving Part Components(PP-0500000)

89
6 Cross flat-head screw
M4*6（chrome plated）
18
5 PP-0505000
Push-rod components
1
4 PP-0504000
Horizontally-moving
motor-components
1
3 PP-0503000
Longitudinally-moving
rail-components
1
2 PP-0502000
Horizontally-moving rear-rail
components
1
1 PP-0501000
Horizontally-moving front-rail
components
1
SN Name Qty
Drawing No.
Materials/specifications
Note
2
1
1
1
5
1
3
1
4
1
6
4
6
4
6
3
6
7
Note：1. This drawing is only for installation
2. The relevant screws are provided in their respective components
6.7 General moving part components (PP-0500000)
1.6.LS240012
