6.5 Coin-door components (PP-0300000)
85
6
1
9
4
8
4
1
1
2
1
10
7
3
1
5
1
4
1
7
4
10
Cross flat-head screw M4*6（chrome plated）
7
9
Carriage bolt
M4*12（chrome plated）
4
8
Hexagon nut with flange
M4（color coating）
4
7
Hexagon nut with flange
M3（color coating）
4
6
Electronic side-vertical
coin-acceptor
TW-130B
1
5
Straight locking-plate, short
4cm(No.003）
1
4
Same-type lock
B17 No.6687（Height 17mm）
1
3
Round loudspeaker
4' 8Ω/15W
1
2 PP-0300A02
Coin-door hinge
1
1 PP-0300A01
Coin-door
1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.6.LS240012
1.6.LSP41022
1.6.LM204013
1.6.LM203013
1.4.TB100030
1.4.SJ500020
1.4.SJ120140
1.4.YS104040
