WAHLAP TECH PUSHING POINTS - Large Acrylic-Door Components(PP-0402000 )

6.6.2 Large acrylic-door components (PP-0402000)
88
12
Hexagon nut with flange
M4（color coating）
6
11
Cross round-head screw M4*6（chrome plated）
24
10
Cross countersunk-head screw
M3*6（chrome plated）
24
9
Same-type lock
B17 No.6687（height 17mm）
1
8
Adjustable-damp hinge
HHPTFB8 3
7 PP-0402D02
Front-door hanging-sticker
PVC-0.2T 1
6 PP-0402D01
Large transparent door-plank
PMMA-5.0T 1
5 KC-0402A07
Lock plate
SPCC-2.0T 1
4 KC-0402A05
No.3 door-frame pressing-iron
SPCC-1.5T 2
3 KC-0402A03
No.1 door-frame pressing-iron
SPCC-1.5T 1
2 PP-0402A02
No.2 door-frame pressing-iron
SPCC-1.5T 6
1 PP-0402A01
Door-frame pressing-iron
SPCC-1.5T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
4
2
5
1
6
1
1
1
4
2
2
6
3
1
9
1
10
4
10
4
11
12
10
12
8
3
12
6
10
4
11
4
11
4
7
1
11
4
Note：The adjustable end shall face up for adjusting.
1.6.LM204013
1.6.LS840012
1.6.LSC30022
1.4.SJ120140
1.4.HY010040
