6.7.1 Horizontally-moving front-rail components (PP-0501000)
90
13
Cross flat-head screw M3*6（chrome plated）
4
12
Cross round-head screw
M4*6（chrome plated）
4
11
Hexagon flat-head screw
M4*8（chrome plated）
4
10
Hexagon flat-head screw
M5*8（chrome plated）
6
9
Hexagon flat-head screw
M4*6（chrome plated）
6
8
Cross round-head screw
M4*10（chrome plated）
10
7
Linear guide MGW 15H-600 1
6
Drag chain
18*18－510Long semi-closed
1
5 PP-0501A05
Horizontally-moving slide-frame
SPCC-1.5T 1
4 PP-0501A04
Horizontally-moving rack iron-pad
SPCC-1.2T 1
3 PP-0501A03
Horizontally-moving rack
nylon
1
2 PP-0501A02
Cover plate for control-panel
service-hatch
SPCC-1.2T 1
1 PP-0501A01
Front horizontally-moving
fixing-board
SPCC-1.2T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
6
1
5
1
7
1
3
1
2
1
1
1
8
10
12
4
9
2
4
1
9
4
13
4
10
6
11
4
Note：When sliding out of
the guide-rail, the the
joystick-ball will drop. Please
be careful when installing!
1.6.LS230022
1.6.LS840012
1.6.LS140032
1.6.LS150012
1.6.LS140012
1.6.LS741012
1.4.DG010041
1.8.AA000133
