WAHLAP TECH PUSHING POINTS - Net Components(PP-0701000)

6.8.1 Net components (PP-0701000)
103
5
1
6
1
4
2
1
1
2
1
10
1
14
8
14
2
13
2
3
1
13
2
15
2
15
2
7
6
15
6
16
2
8
3
15
6
9
1
11
3
12
1
17
4
17
Hexagon flat-head screw M4*6（chrome plated）
4
16
EVA sponge
(single-side adhesive)
2*18mm 10M/roll
2
15
Plastic-head screw
M4*8（white）
16
14
Hexagon nut with flange
M4（color coating）
10
13
Cross flat-head screw
M4*6（chrome plated）
4
12 PP-0701D03
Front prize baffle
PVC-1.0T 1
11 PP-0701D01
Prize baffle - long
PC-3.0T 3
10 PP-0701A11
Right net beam-iron
SPCC-1.5T 1
9 PP-0701A09
Prize baffle - small
1
8 PP-0701A08
Baffle layering
SPCC-1.2T 3
7 PP-0701A07
net tablet
SPCC-1.2T 6
6 PP-0701A06
Inside net cover-plate
SPCC-1.2T 1
5 PP-0701A05
Outside net cover-plate
SPCC-1.2T 1
4 PP-0701A04
Lower net layering
SPCC-1.0T 2
3 PP-0701A03
Left/right net borders
SPCC-1.2T 1
2 PP-0701A02
Lower net back-frame
SPCC-1.0T 1
1 PP-0701A01
Lower net front-frame
SPCC-1.0T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.6.LS140012
1.9.HM020020
1.6.LSU40800
1.6.LM204013
1.6.LS240012
