Upward adjustment steps for the ramp net
5.2.34 Specification for the height of the ramp net
1. Open the acrylic door with the key and remove 2 rubber-head cross-groove screws to fix both
net side-plates.
2. Remove 2 screws to fix the net pin-seat, move the net pin-seat up to the screw hole and then
fix the net pin-seat with 2 screws.
3. Use 1 rubber-head cross-groove screw to fix both net side-plates.
4. Remove 6 screws to fix the prize ramp net, move the prize ramp net up to the screw-hole and
then fix the prize ramp net with 6 screws.
Note: For backward adjustment, the 4th step shall be completed first, then the 1st , 2nd and
3rd step.
There are 2 kinds
of adjusting-height
There are 2 kinds of adjusting-height for the ramp net, such as upward adjustment or
backward adjustment.
59
