5.2.35 Descriptions for damping-adjustable hinge
1. Open the acrylic door with the key and the player can see 3 damped adjustable-hinges
located in the acrylic door.
2. Use the 6-point wrench to adjust the damping. When adjusting clockwise, the damping
becomes greater. When adjusting counterclockwise, the damping becomes smaller. The
damping affects the opening of the large acrylic door.
5.2.36 Description for power socket
2 power sockets：AC110V and 230W in all
Warning
1. Open the acrylic door with the key and there is a power socket in the upper right corner of
the game-machine.
2. Remove 2 screws to fix the left small-door and player can see a power socket on the left.
60
