11
Remove POP components and screw
it onto the top of the game-machine.
Before the game-machine is powered on, cut off the cable ties at this
position (for fixing X/Y axes of moving parts during transportation).
On the contrary, when the game-machine is moved, the position
must be tightened with the cable ties!
Warning
Note：X/Y axes of moving
parts are provided with 2
cable ties respectively!
2.6 Instructions for installation
Fix POP components to the top of the game-machine with 5 screws.
