WAHLAP TECH PUSHING POINTS - Replacement of Fuse; Change Power-Box

5.2.28 Change power-box
5.2.27 Replacement of fuse
55
1.Turn off the game-machine, screw off fuse holder counterclockwise with Philips driver.
2.Remove fuse from fuse holder,and install in reverse sequence after replacement.
Fuse of AC220Vmachine: T3.15A/5×20mm 250V
Fuse of AC110Vmachine: T4A/5×20mm 125V
3. Remove 4 screws to fix the transparent PVC power-box cover.
1. Turn off the game-machine and remove 6 screws to fix the back-door.
2. Remove 2 nuts to fix the power-box fixing-plate and pull out the power-box fixing-plate.
It must be operated by technicians
