USER RELAYS - PROGRAMMING PROCEDURE
Table 9. User-Programmable User Relays - Funcon Opons
No� Name Descripon
5 Warn before/during
operate output
Controls an external warning device. This output operates at
the same me as the internal “warn before operate” buzzer.
6 Gate Lock output Controls external solenoid locks or magnec locks. In both
direcons of travel, this output is acvated about 7/10ths of a
second before the operator starts moving the gate and remains
acve while moving as well as for a few seconds aer stopping.
7 Gate forced open output Acvated if the gate is forced o the closed limit switch
and operator is not able to restore the gate to fully closed
within four seconds. The alarm resets itself in 30 seconds.
8 Gate open too long
output
Acvates when the gate is open longer than a user-selected
period of me. Adjustable from a 0 second to 135 second delay in
30-second increments.
Note: TL - OPEN TIME ALERT adjustments can be made in the
Installer Menu.
9 Safety Mode Alert output Acvated when system is in Safe Mode or Entrapment Mode.
10 Entrapment Mode Alert
output
Acvated only when system is in Entrapment Mode.
11 Unauthorized Vehicle
Entry output
Acvated when a second vehicle enters from the outside without
a valid input from an access control device. The OOLD and IOLD
loops must be capable of being triggered at the same me for this
relay to ever acvate. This output releases when an access control
input signals open or the gate reaches the close limit posion.
12 Outside Obstrucon
Vehicle Detector output
Interlocks an entry device to prevent pedestrian use. This output is
acve whenever the Outside Obstrucon Loop Detector is tripped.
13 Loitering Alert Indicates a vehicle is loitering on the Outside Obstrucon Loop.
Adjustable from a 0 second to 135 second delay in 30-second me
intervals.
Note: LT - LOITERING ALERT adjustments can be made in the
Installer Menu.
