Maintenance
1224−1/A1
Winterthur Gas & Diesel Ltd.
7/ 7
4. Completion
1) Install the end casing (1, Fig. 7).
2) Install the beam (2).
3) Remove all tools and equipment from the area.
Fig. 7
1
2
WCH02906
2015
Thrust Bearing Pads − Removal and Installation
