Xerox B310 Service Manual

PPrreeccaauuzziioonnii ppeerr llaa rriimmoozziioonnee
ATTENZIONE – PERICOLO DI SCOSSA ELETTRICA: Sull'alimentatore a bassa tensione (LVPS)
e l'alimentatore ad alta tensione (HVPS) può essere presente tensione residua. Per evitare il
rischio di scossa elettrica, non toccare i loro componenti elettrici o il lato saldatura della scheda.
Toccarli soltanto dai bordi esterni o dall'alloggiamento in metallo.
ATTENZIONE – PERICOLO DI SCOSSA ELETTRICA: Questo prodotto utilizza un interruttore di
alimentazione elettronico. Tale interruttore non scollega fisicamente la tensione CA in entrata.
Per evitare il rischio di scossa elettrica, rimuovere sempre il cavo di alimentazione dalla
stampante quando è necessario rimuovere la tensione CA in entrata.
ATTENZIONE – PERICOLO DI SCOSSA ELETTRICA: Per evitare il rischio di scossa elettrica e
per impedire danni alla stampante, rimuovere il cavo di alimentazione dalla presa elettrica e
scollegare tutti i collegamenti a eventuali dispositivi esterni prima di collegare o scollegare
qualsiasi cavo, scheda elettronica o gruppo.
ATTENZIONE – SUPERFICIE SURRISCALDATA:L'area interna della stampante potrebbe
surriscaldarsi. Per evitare infortuni, lasciare raffreddare la superficie dei componenti prima di
toccarla.
ATTENZIONE – PERICOLO DI SCHIACCIAMENTO: Per evitare il rischio di lesioni, prestare la
massima cautela quando si accede alle aree contrassegnate con questa etichetta. Potrebbero
infatti verificarsi lesioni da schiacciamento in prossimità di parti in movimento, quali ad
esempio ingranaggi, porte, vassoi e coperchi.
HHaannddlliinngg EESSDD--sseennssiittiivvee PPaarrttss
Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To
prevent damage to ESD-sensitive parts, do the following:
• Turn off the printer before removing logic boards.
• Keep the parts in their original packing material until you are ready to install them into the
printer.
• Make the least possible movements with your body to prevent an increase of static electricity
from clothing fibers, carpets, and furniture.
• Put the ESD wrist strap on your wrist. Connect the wrist band to the system ground point. This
action discharges any static electricity in your body to the printer.
• Hold the parts by their edge connector shroud. Do not touch its pins. If you are removing a
pluggable module, then use the correct tool.
• If possible, keep all parts in a grounded metal cabinet.
• Do not place the parts on the printer cover or on a metal table. If you need to put down the parts,
then put them into their packing material.
• Prevent parts from being accidentally touched by other personnel. Cover the printer when you are
not working on it.
• Be careful while working with the parts when cold-weather heating is used. Low humidity
increases static electricity.
Xerox
®
B310 Printer
Service Manual
139
Parts Removal

Xerox B310 Specifications

General

Color	Yes
Print technology	Laser
Resolution color	4800 x 4800 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.7 s
Time to first page (color, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
PCL fonts	6
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	80000 pages per month
Recommended duty cycle	0 - 6000 pages per month
Number of PostScript fonts	158
Number of print cartridges	4
Page description languages	HTML Direct Image Space, PCL 5, PCL 6, PDF 1.7, PostScript 3, XPS
Processor frequency	1000 MHz
Sound pressure level (printing)	50 dB
Sound pressure level (duplex printing)	52 dB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8, Windows 8.1
Total input capacity	251 sheets
Total output capacity	125 sheets
Paper tray 1 input capacity	250 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	98 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Cables included	AC
Included cartridge capacity (CMY)	1500 pages
Included cartridge capacity (black)	1000 pages
Display	LCD
Control type	Buttons
Product color	Blue, White
Display diagonal	2.4 \
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	47-63 Hz
Power consumption (max)	530 W
Power consumption (off)	0.2 W
Power consumption (standby)	22 W
Power consumption (printing)	360 W
Power consumption (PowerSave)	1.61 W
Harmonized System (HS) code	84433210
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	15 - 80 %
Package depth	567 mm
Package width	534 mm
Package height	450 mm
Package weight	23800 g

Weight and Dimensions

Depth	421 mm
Width	442 mm
Height	308 mm
