5. Remove the two screws, and then remove the cover.
PPrriinntthheeaadd RReemmoovvaall
Note: For a video demonstration, see Printhead Removal.
1. Remove the right cover. See Right cover removal.
2. Remove the left cover. See Left cover removal.
3. Disconnect the control panel cables. See Control Panel Removal.
Note: Do not remove the control panel from the top cover.
4. Remove the top cover. See Top Cover Removal.
Xerox
®
B310 Printer
Service Manual
175
Parts Removal
