Xerox B310

2. Disconnect all the cables from the controller board.
3. Remove the five screws, and then remove the controller board.
LLVVPPSS RReemmoovvaall
Note: For a video demonstration, see LVPS removal.
1. Remove the right cover. See Right cover removal.
158
Xerox
®
B310 Printer
Service Manual
Parts Removal
