Xerox B310

Xerox
®
B310 Printer
Service Manual
227
12
Part Number Index
P/N Part name
002N03399 Right cover
002N03400 Left cover
002N03411 Top cover with control panel
002N03412 Upper front cover with decals
002N03424 Front door with MPF pick roller
002N03427 Rear door
002N03428 Left front door link
005N01213 Pick roller clutch
007N01855 Main drive gears kit
007N01857 Redrive
022N02902 Pick separator roller
022N02903 Transfer roller, bearing, and spring
022N02904 550-sheet tray pick roller
032N00557 Duplex guide
046N00243 Printhead
050N00722 550-sheet tray insert
050N00717 250-sheet tray
109N00869 Controller board
112N00265 LVPS, 110V
112N00266 LVPS, 220V
112N00269 HVPS
120N00574 Bin full sensor actuator
126N00458 Fuser, 110 V
126N00459 Fuser, 220V
127N07968 Main fan
130N01897 Sensor (input)
