Assembly 3: Gears
Asm-index P/N Units/mach Units/FRU
Description
Removal
procedure
1 005N01213 1 1 Pick roller clutch Pick Roller
Clutch Removal
2 007N01855 1 24 Main drive
gears kit
Main drive
gears removal
198
Xerox
®
B310 Printer
Service Manual
Parts Catalog
