Connector Connects to Pin number
Signal
3 BRAKE
4 PWM
5 DIR
6 FG
7 +25 V_SW
8 GND
Sensor (toner density) 9 LED_PWM_TDS
10 THERM_TDS
11 SNS_TDS
12 GND
13 PWR_TDS
Pick clutch 14 +25 V_SW
15 CLUTCH_SINK
Sensor (input) 16 SNS_INPUT
17 GND
18 PWR_INPUT
JTRAY1 Tray present switch 1 PWR_TRAY
2 TRAY_DETECT
JOPT1 Paper handling option 1 +25 V_SW
2 TXD_OPT
3 TRAY_PULLED_N
4 RXD_OPT
5 GND
6 5 V_OPT
JLVPS1 LVPS 1 RELAY_ON
2 HEAT_ON
3 ZERO_CROSS
4 +25 V_SW_ON
5 +25 V_CONT_RAIL
6 GND
7 +25 V_SW_RAIL
8 GND
