Product Overview
Xerox
®
DocuCentre
®
SC2020
User Guide
43
Right Side, Rear
4 Right top tray Copies and prints are delivered here, facing down.
5 Front cover Open this cover to replace consumables.
6 Tray 1 (standard tray) Load paper here.
7Tray 2
(One Tray Module)
(Optional)
Optional tray. Load paper here.
8 Left side cover [B] Open this cover to remove any jammed paper from Tray 2.
9 Tray 5 (bypass) Load paper here. The tray can be extended.
10 Left side cover [A] Open this cover to remove any jammed paper.
Note: When the device works properly, this cover is locked. To open
this cover, make sure to exit Sleep mode and turn the device's
power OFF.
No. Component Description
1 Ethernet Port Connect a network cable.
2 USB Port Connect a USB 2.0 cable.
3 Power switch Switches the power of the device on and off.
For more information, refer to
Power Source on page 45.
No. Component Description
To Next Page
