1-4 Phaser 6121MFP Service Manual
General Information
Parts of the Printer
Front Views
Item Description Item Description
1 Document Output Tray 9 Document Cover
2 ADF (Auto Document
Feeder) Cover
10 Output Tray
3 ADF Guides 11 Tray 1
4 ADF Tray 12 Tray 1 Dust Cover
5 Document Stopper 13 Front Door
6 Printer Top 14 Tray Extension
7Power Switch 15Control Panel
8 USB Drive Port 16 Document Glass
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
s6121mfp-017
