Phaser 6121MFP Service Manual 9-11

Parts List

Part List 2.0 Scanner

Item Part Name Part Number

1 Cover (Original) XC —

2 Label Copy Prohibition —

3 Pulley Assembly —

4 Scanner Unit 4in1 109K02310

Scanner Unit 3in1 109K02320

5 Control Panel (3in1) Assembly 848K42910

Control Panel (4in1) Assembly 848K42920

6Cover Assembly XC —

Cover Assembly XC —

7 Sheet XC —

8 Vibration Proof Part —

9Flat Cable —

10 Shaft —

11 Driving Assembly —

12 Tape —

13 CIS Assembly —

14 Timing Belt —

15 Control Panel (3in1) —

Control Panel (4in1) —

16 4-in-1 Bezel 056E05460

3-in-1 Bezel 056E05470

17 Phaser 6121MFP/N Bezel, 110V (4-in-1) 897E31830

18 Phaser 6121MFP/S Bezel, 110V (3-in-1) 897E31880

19 Phaser 6121MFP/N Bezel, 220V (4-in-1) —
