Xerox PHASER 6121MFP - Image Transfer Solenoid

Phaser 6121MFP Service Manual 8-103
Service Parts Disassembly
Image Transfer Solenoid
PL9.1.9
1. Remove the Rear Cover (page 8-28).
2. Remove the Right Side Cover (page 8-29).
3. Remove the Left Side Cover (page 8-28).
4. Remove the Scanner (page 8-31).
5. Disconnect all harnesses from the Engine Control Board.
6. Remove the harnesses from the harness guide.
