Phaser 6121MFP Service Manual 8-29
Service Parts Disassembly
4. Remove 2 screws (metal, 10 mm) that secure the left side cover.
Right Side Cover
PL 3.0.1
1. Open the top cover.
2. Open the front cover.
s6121mfp-002
