Phaser 6121MFP Service Manual 8-109
Service Parts Disassembly
500-Sheet Feeder Tray
500-Sheet Feeder Tray (PL15.0)
Whenever removing or reinstalling the feeder, unplug the power cord of the
printer from the power outlet first.
1. Lift the printer main body and then remove the 500-Sheet Feeder Unit from
the printer.
To Next Page
