Xerox PHASER 6121MFP - Fuser

Phaser 6121MFP Service Manual 2-13
Theory of Operation
Fuser
Functional components of the Fuser appears below.
Fuser Drive
The Fuser is driven by the Main Motor.
s6121mfp-111
Thermostat
Exit Sensor (PS7)
Pressure Roller
Thermistor (TH1)
Heater Lamp
Fusing Roller
s6121mfp-162
