Phaser 6121MFP Service Manual 2-5
Theory of Operation
Paper Path of the Printer
Print Engine Paper Path
The print media is supplied from Tray 1 or the optional Tray 2, and is transported
into the printer along the paper path as shown in the diagram.
Item Description
1Output Tray
2Tray 1 (MPT)
3 Tray 2 (Optional 500-Sheet Feeder)
s6128mfp-107
1
2
3
