Xerox PHASER 6121MFP - Duplex Unit Transport Sensor

8-108 Phaser 6121MFP Service Manual
Service Parts Disassembly
Duplex Unit Transport Sensor
PL14.1.7
1. Remove the Duplex Unit (page 8-110).
2. Disconnect P/J52, and then remove the Transport Sensor.
s6121mfp-377
P/J52
