8-56 Phaser 6121MFP Service Manual
Service Parts Disassembly
Transfer Roller
PL7.1.10
1. Remove the Imaging Unit (page 8-6).
2. Remove the Transfer Roller by squeezing the white tabs of the holders located
on both sides, and then pull out the roller.
s6121mfp-230
Transfer Roller
