Phaser 6121MFP Service Manual 8-73
Service Parts Disassembly
7. Open the wire guides and unlace the Front Door Switch wires from the guides.
8. Remove 2 screws (metal, 6mm, with lock washer and washer) from the power
switch.
s6121mfp-237
s6121mfp-327
