Phaser 6121MFP Service Manual 9-27

Parts List

Part List 8.0 Paper Exit Section

Item Part Name Part Number

Screw

1. Included in Hardware Kit, see page 9-54.

826E54980

E-ring

115E13110

Bushing /Right

016E20270

2 Ground Spring —

3 Actuator —

4Holding Guide —

5 Pulling Coil spring —

6Holder —

7 Compressing Coil Spring —

8Holder —

9 Balancer /Right —

10 Rail —

11 Plate Spring —

12 Paper Exit Tray —

13 Lever /Right —

14 Guide —

15 Cover —

16 Lever /Left —

17 Balancer /Right —

18 Cover —

Media Full Sensor

130E18330

Wiring

(see “Wiring Kit” on page 9-55)

2. Include in Wiring Kit, see page 9-55.

—

21 Duct —

22 Exit Tray Cooling Fan —

23 Upper Cover —
