Phaser 6121MFP Service Manual 9-31

Parts List

Part List 9.2 Drive Section (2/2)

Item Part Name Part Number

1 Lever —

2 Lever —

3 Lever —

4 Torsion Coil Spring /Left —

5 Torsion Coil Spring —

6Mounting Plate —

7Ratchet —

8Gear 52T —

9Lever —

10 Lever —

11 Pulling Spring —

12 Gear 17T —

13 Gear 54/42T —

14 Compressing Spring —

15 Gear 45T —

16 Gear 45T —

17 Gear 27/40T —

18 Cam —

19 Lever —

20 Torsion Coil Spring —

21 Compressing Spring —

22 Seal —

23 Protection Part —

24 Cleaning Blade Solenoid —

25 Cleaning Blade Solenoid Assembly 604K61490
