Phaser 6121MFP Service Manual 9-33
Parts List
Part List 10.0 Right Guide Section
Item Part Name Part Number
1 Pulling Coil Spring 809E95470
2 Contact —
3 Torsion Coil spring /Right —
4Lever —
5Contact —
6 Fixing Lever /Right —
7 Plate Spring /Right —
8Guide /Left —
9Holder —
10
Contact
1
1. Included in Hardware Kit, see page 9-54.
115E13120
11 Contact —
12 Guide —
13 Fixing Lever /Left —
14 Spring —
15 Guide /Right —
16 Spring —
17 Mounting Plate —
18 Contact —
19 Lever —
20 Torsion Coil Spring —
21
Wiring
2
2. Included in Wiring Kit, see page 9-55.
—
