Phaser 6121MFP Service Manual 9-55
Parts List
Wiring Kit
The wiring kit contains the following components.
Time Belt 023E31770
Roll 059E11010
Bushing 016E20260
E-ring 115E13090
Pin 115E13100
Guide 032E40590
Spacer 014E68450
Time Belt 023E31780
Compression, Coil Spring 809E95520
Bushing 016E20270
E-ring 115E13110
Spring, Contact 115E13120
Photo Interrupt Sensor 130E18330
Wiring Kit, Part Number 604K61510
Part List Item Number(s)
PL4.0 13
PL6.0 15
PL8.0 20
PL9.1 16
PL10.0 21
PL12.0 15
PL13.0 13, 15, 16
Hardware Kit (continued)
Description Part Number
To Next Page
