Xerox Phaser 8500 - X-Axis Motion (8400 Only)

Phaser 8400/8500/8550/8560 Color Printer Service Manual 5-35
Print-Quality Troubleshooting
X-Axis Motion (8400 Only)
N
o
t
e
For X-Axis Motion problems, see “Analyzing Service Test Prints” on
page 5-34 (solid fill prints).
This print is used by Engineering and Manufacturing. The print must be
printed on Xerox Photo Paper. Using a lower grade paper will result in
inaccurate measurements.
s8500-049
