8-2 Phaser 8400/8500/8550/8560 Color Printer Service Manual
Service Parts Disassembly
Overview
This section contains the removal procedures for selected printer parts listed
in the Field Replaceable Units (Service Parts) Parts List. In general,
replacement procedures are not given because re-installing a part is usually
simply a reversal of the disassembly. Replacement procedures are included
where this is not the case and special steps are required. Replacement notes
are included when they can help ease or shorten the reassembly process.
Standard Orientation of the Printer
When needed the orientation of the printer is called out in the procedure for
locating printer parts. Refer to the printer orientation graphic for locating the
right, left, front and back sides of the printer.
s8500-002
Left
Right
Back
Front
