Xerox Phaser 8500 Service Manual

1-12 Phaser 8400/8500/8550/8560 Color Printer Service Manual
General Information
Functional Specifications
Electrical Specifications
Environmental Specifications
Characteristic Specification
Printing Process Solid-ink
Color Medium
Yellow, cyan, magenta, and black ink sticks, each shape-
coded. The printer uses the subtractive color system to
produce the colors red, green, and blue.
Operating Modes and
Resolutions
(8400)
Fast Color (300x300 dpi), Standard (300x450 dpi), Enhanced
(563x400 dpi), High Resolution/Photo (525x2400)
(8500/8550/8560)
Fast Color (225x400 dpi), Standard (300x450 dpi), Enhanced
(525x400 dpi), High Resolution/Photo (525x2400)
Maximum Operating
Printing Speed
24 ppm (8400 and 8500 series)
30 ppm (8550 series)
First-Print-Out
(Letter/A4)
As low as 6 seconds
Warm-Up Time:
From Off (cold start)
From Power Saver
12 minutes (8400), 15 minutes (8500/8550/8560)
4 minutes
Characteristic Specification
115 Volt 230 Volt
Primary line voltages 90 - 140 VAC 180 - 264 VAC
Primary line voltage
frequency range
47 - 63 Hz 47 - 63 Hz
Power consumption 1250 W (peak) - 1000 typical
180 W (idle)
230 W (average during
printing)
1250 W (peak) 1000 typical
180 W (idle)
230 W (average during
printing)
Energy Star® 43 W 43 W
Nominal Operating Environment
Temperature 10º - 32º C (50º - 90º F) operating
20º - 25º C (68º - 77º F) Best jam performance
Humidity 10% - 80% RH Non-Condensing operating
