1-10 Phaser 8400/8500/8550/8560 Color Printer Service Manual
General Information
Printer Specifications
Physical Dimensions and Clearances
Print Engine Only Value
Width: 422 mm (16.6 in.)
Depth: 514 mm (20.24 in.)
Height: 368 mm (14.48 in.)
Weight: 26.8 kg (59 lb.)
Optional 525-Sheet Feeder Value
Width: 422 mm (16.6 in.)
Depth: 514 mm (20.24 in.)
Height: 132 mm (5.2 in.)
Weight: 5.4 kg (12 lb.)
Minimum Clearances Supplemental Information
Left side and rear - 102 mm (4 in.) Required for airflow.
Right side - 394 mm (15.5 in.) Required for maintenance kit and waste tray
access, and airflow.
Front - Unrestricted Required for media tray and jam access.
Top - 559 mm (22 in.) printer only Required for inkload and jam access.
Bottom - No obstruction between
mounting surface and printer
Required for airflow.
Min. install width - 711 mm (28 in.) Requires placing printer at an angle to remove
waste tray.
