3-24 Phaser 8400/8500/8550/8560 Color Printer Service Manual
Error Messages and Codes
N
o
t
e
Xerox is not financially responsible for the incorrect operation of its
products caused by the use of non- Xerox ink.
9,009.44 and 9,00X.6x Errors - Program Faults
9,009.44: This fault indicates a device failure attempting to access NVRAM.
a. Reset NVRAM and retest.
b. Ensure ground integrity for the printer (see “Ensuring Ground
Integrity” on page 4-65).
11,0XX.xx Errors - Electronics Module Interface Fault
11,001.47: Upper 525-sheet feeder broken serial link detected.
11,002.41: Lower 525-sheet feeder broken serial link detected.
11,002.48: Lower 525-sheet feeder broken serial link detected.
11,003.42: Control Panel broken serial link detected.
11,003.49: Control Panel broken serial link detected.
11,004.41: Control Panel or I/O Board broken serial link detected.
11,004.43: I/O Board broken serial link detected.
11,005.42: Power control broken serial link detected.
11,005.44: Power control broken serial link detected.
3 Test the Ink Count Sensor by running
the Monitor Sensors test in Service
Diagnostics.
Insert the clean, eraser end of a pencil
thru the lowermost oval slot in the Ink
Loader. Actuate the appropriate sensor
by sliding the pencil down the white
channel guide until the sensor is
tripped. If the sensor is functional, a
state change appears on the Control
Panel as <color> Ink Present H. When
released, the reading changes to L.
The test only displays a reading when a
sensor change occurs. If a flag is
stuck, no reading is displayed.
Did the test pass?
Check for
defects in the
genuine Ink
Sticks. If no
defects are
found, go to
Step 4.
Replace ink if
necessary.
Replace the Ink
Loader.
4 Test the ink melt heaters.
Run the appropriate Ink Melt [1, 2, 3,
4] Heater test.
1 = Yellow
2 = Cyan
3 = Magenta
4 = Black
Did the test pass?
Replace the
Printhead.
1. Replace the Ink
Loader.
2. Run Clear ISC
Fault test to clear
the error.
Troubleshooting Procedure for Ink Loader (Continued)
Step Questions and Actions
Yes No
