A-6 Phaser 8400/8500/8550/8560 Color Printer Service Manual
Reference
Media Margin Specification Table
Media Size
Width
(mm)
Length
(mm)
Side
Margins
(mm)
Top/
Bottom
Margin
(mm)
Width
(mm)
Length
(mm)
Legal 215.9 355.6 5 5 205.9 345.6
Folio 215.9 330.2 5 5 205.9 320.2
A4 210 297 5 5 200 287
A 215.9 279.4 5 5 205.9 256.7
Executive 187.15 266.7 5 5 174.15 256.7
B5 JIS 182 257 5 5 172 247
B5 ISO 176 250 5 5 166 240
#10 Envelope 104.775 241.3 5 15 94.775 211.3
Choukei 3 Gou 120 235 5 15 105 205
C5 Envelope 162 229 5 20 157 189
DL Envelope 110 220 5 20 100 180
Statement 139.7 215.9 5 5 129.7 205.9
A5 148 210 5 5 138 200
Choukei 4 Gou 90 205 5 15 80 175
Monarch
Envelope
98.425 190.5 5 15 88.425 160.5
A7 Lee Envelope 133.35 184.2 5 15 123.35 154.2
#6 3/4 Envelope 92.075 165.1 5 15 82.075 135.1
A6 105 148 5 5 95 138
#5-1/2 Baronial 111.125 146 5 15 101.125 112.9
3 x 5 Card 76.2 127 5 5 66.2 117
6 x 9 Envelope 152.4 228.6 5 20 142.4 188.6
Custom 76.2 -
215.9
127 -
355.6
12.5
(8400)
5 mm
(8500)
12.5 51.2 -
190.9
102 -
330.6
