Phaser 8400/8500/8550/8560 Color Printer Service Manual 10-9
Inside Top Wiring Diagram
The arrows indicate which connectors you should look at for the PEST codes.
The PEST codes are displayed on the Control Panel.
37010.4x
Ink 1 Heater
J130 34062.4x (Data Cable)
J1AC 37009.4x
(Ink Load Power)
J2AC 37002.4x
JSL Heater
s8500-130
37010.4x
Ink 1 Heater
J130 34062.4x (Data Cable)
J1AC 37009.4x
(Ink Load Power)
J2AC 37002.4x
JSL Heater
8400
8500/8550
