Xerox Phaser 8500 Service Manual

9-16 Phaser 8400/8500/8550/8560 Color Printer Service Manual
Parts Lists
Xerox Supplies
Kits
Description Part Number
Mechanical Kit (Hardware)
■ Nut Plate - 2 ea.
■ 6 mm press nut - 2 ea.
■ #8 SAE washer - 5 ea.
■ Thumbscrews - 2 ea.
■ M4 x 12 delta pt/ hexhead - 5 ea.
■ M4 x 32, partial thread flanged hex - 5 ea.
■ M4 x 32, partial thread flanged hex, left-hand
thread, yellow - 5 ea.
■ M4 x 12, taptite flanged - 5 ea.
■ ASMO clip, lift motor - 2 ea.
■ E-ring, bent M6 5 mm - 5 ea.
■ Bushing 6 mm - 2 ea.
■ Cable Restraint - 2 ea.
■ Left-hand Drum screw (yellow - 2 ea.)
■ Frame Replace Screw (red tint - 5 ea.)
604K42210
Repackaging Kit 065062800 (8400)
659K22810 (8500/8550/8560)
Cleaning Kit 016184500
Power Cords
Description Part Number
Cable Assembly, 3,18 AWG, 115 V, 98, 0 L 117E29520
Cable Power EURO 220 V, 99 L 117E29500
Cable Power U.K. 240 V, 96 L 117E29510
Cable Power AUST 240 V, 96 L 117E29490
Cable Assembly SWISS 220/240 V, 50 Hz 117E35050
Cable Assembly PWR. DANISH, 250 V 117E29460
Cable Assy PWR, CHINESE 117E35030
Cable Power, 240 V, ARGENTINA 117E35040
Upgrade Kits and Options
Description Part Number
Hard Drive Upgrade Kit 097S03172 (8400)
121K44410 (8500/8550/8560)
Hard Drive Upgrade with Japanese Fonts 097S03173 (8400)
121K44420 (8500/8550/8560)
