Phaser 8400/8500/8550/8560 Color Printer Service Manual 9-15
Parts Lists
Parts List 6.0 Sensors and Flags (Actuators)
No. Name/Description Qty Part Number
1 Drum Temperature Sensor 1 130K75210
2 Optical Sensor (Generic Snap-In) 1 130E11530
3 Safety Interlock Switch (Mech) 1 110E20390
4 Exit Module Sensor Assembly 1 130K75220
5 Paper Present Flag 1 130E11550
6 Exit Flag 1 386732680
7 Sensor Assembly, Paper Tray 1 130K75230
8 Waste Tray Detect Sensor 1 130E12620
